| 品牌 | ENOVOR |
|---|---|
| 型号 | HD11MRB-DVI |
FULL HD 1080P P/T/Z robitc video camera for video conferencing HD-DVI HDMI Detailed Product Description
Reliable & cost effective video conferencing
1080P/30 1080i/59.94,50 720P/59.94,50
E-Flip Function
DVI-D digital interface
HD11MRB-DVI is one of the high end High Definition P/T/Z camera models in EVR camera family. It is equipped with DVI-D video output interface and fully support 1080i/60 industry standards. The HD11MRB-DVI is powered by SONY FCB serial HD color camera module and driven by our unique 360 degree fast speed pan. Many innovative technology were also applied to this advanced camera model, such as OSD (On Screen Display), 128 preset positions and this is the first HD P/T/Z camera that can be mounted on the ceiling (image up side down function).All EVR camera models completely compatible with SONY VISCA, PELCO: P/D, RS-232 and Rs422 protocols. KEY FEATURES:40X zoom (10X optical, 4X digital)
Image sensor: 1/3 CMOS 200M pixel
Unique image flip function (up-side-down image output) and 360o full view angle
Innovative OSD menu (On Screen Display)
Position pre**p to 128 VISCA preset positions and 32 address for cascading link mode
Optional S-VIDEO and VIDEO output (controlled by menu/IR controller/computer)
Innovative video output live switch function (no power-off needed): among 4 HD video formats and 4 SD video formats
Supports both VISCA and PELCO: P/D protocol
Rich shortcut functions: set/call/modify/revise/input/clear and so on
Power-on self inspection & Remote PC controllable protocol/address/band rate options
Can customize lens zoom speed: up to 7 speed steps
Time display, up to 10 groups of timing triggered motions for position preset scan/vertical-horizontal scan/ position preset multi-point scan
Editable scan spot duration(set from 1 to 255 second)
6 groups of editable horizontal and vertical scan speed (pan: 0.1o/s ~ 90o/s /tilt speed: 0.1o-120o /s)
**p to 6 groups of scan locus for cascading and parallelling mode
Can memory up to 2 groups of scanning pattern for all P/T/Z motions
?Maximum Horizontal Speed (Pan): 0.1~180 o /s, Vertical Speed (Tilt): 0.1 ~ 120 o /s [for OEM product]
Industry-leading P/T/Z camera with the best vivid image quality For detailed product specification and price issue welcome email us. Language Option Switch languge to help reading: French German Italian Russian Spanish Portuguese Korean 日本語
French German Italian Russian Spanish Portuguese Korean 日本語
FULL HD 1080P P/T/Z robitc video camera for video conferencing HD-DVI HDMI Product Details:| Place of Origin | Guangdong, China (Mainland) |
|---|---|
| Brand Name | ENOVOR |
| Model Number | HD11MRB-DVI |
| Image sensor | 1/3 CMOS 2,000,000 pixel |
| Resolution | 1080P/1080i / 720P |
| Zoom | 10 x optical 4 digital |
| Type | Pan / Tilt / Zoom |
| E-Flip | support |
| Output | HD-SDI YPbPr component VBS(BNC) Y/C(4 pin mini DIN) |
