| 类型 | 外置开关电源 |
|---|---|
| 输入电压 | 220 |
| 输出功率 | 24 |
| 品牌 | 格雷特GRT |
| 型号 | POE30L |
INPUT: |
|
|
|
| ||||
AC Input Voltage Range |
|
| EMC | |||||
90 to 264VAC |
|
|
| FCC Part 15 Class B | ||||
AC Input Voltage Rating |
|
| EN55022 Class B | |||||
100 to 240VAC |
|
|
| Isolation Test | ||||
AC Input Current |
|
|
| Primary to Secondary: 3000VAC for 1 minute 10mA | ||||
0.5A(RMS) max. for 90VAC |
|
| Primary to F.G.: 1500VAC for 1 minute | |||||
0.35A(RMS) max. for 240VAC |
|
| Output to F.G.: 1500VAC | |||||
Leakage Current |
|
|
| Immunity EN50082-1 | ||||
0.25mA max. @ 254VAC 60Hz |
|
| ESD: EN61000-4-2. Level 3 | |||||
AC Input Frequency |
|
|
| RS: EN61000-4-3. Level 2 | ||||
47-63Hz |
|
|
|
| EFT: EN61000-4-4. Level 2 | |||
AC Inrush Current |
|
|
| Surge: EN61000-4-5. Level 3 | ||||
15A(RMS) max. for 115VAC |
|
| CS: EN61000-4-6. Level 2 | |||||
20A(RMS) max. for 230VAC |
|
| Voltage Dips EN61000-4-11 | |||||
OUTPUT: |
|
|
|
| Harmonic: EN61000-3-2 | |||
Total Output Power |
|
|
| Insulation Resistance | ||||
24W |
|
|
|
| Primary to secondary: >10M OHM 500VDC | |||
Efficiency |
|
|
| Primary to FC: >10M OHM 500VDC | ||||
80% (typical) at Max. load, and 120VAC 60Hz |
| FEATURE: | ||||||
Hold-up Time |
|
|
| Over Voltage/Current, Short Circuit Protection | ||||
16mS min. 120VAC and max. load |
|
| The output can be shorted permanently without damage | |||||
Transient O/P Voltage Protection |
| Indicators | ||||||
60V max. at switch on and off at any AC line Phase | Led #1 indicator for input power “on” GREEN | |||||||
ENVIRONMENTAL: |
|
|
| Input Connector | ||||
Temperature |
|
|
| IEC320 inlet 3 pin | ||||
Operation 0 to +40°C |
|
|
| Data Connector | ||||
Non-operation -25 to +65°C |
|
| RJ45 +48V pins3&6/4&5, Power Return pins1&2/7&8 | |||||
Humidity |
|
|
|
|
| |||
Operation 5 to 90% |
|
|
|
| ||||
